Tire Features
Cut And Chip Tread Compound
The tread compound helps resist cuts and chips in mixed service applications.
Stone Protector Ledges
Stone protector ledges on all grooves help resist stone penetration and retention.
Curb Bar With Sidewall Depth Indicator
The curb bar with sidewall depth indicator helps protect the sidewall from scuffing damage and assists in indicating when a tire should be rotated to preserve the casing for retreading.
Deep Tread Depth
The 22.5/32' tread depth helps provide long miles to removal in on/off-road applications.
High Tensile Strength Four-Belt Package
The high tensile strength four-belt package helps provide casing durability and retreadability.
Warranties & Guarantees
2023 Commercial Replacement Tire Guide, Limited Warranty & Registration Booklet For Cooper® & Roadmaster® Tires
Tire Specifications
Tire Specifications
Full Specs
- Tire Size 12R22.5
- Static Loaded Radius 0 in/ 0 mm
- Load Range H
- Tread Depth 22 / 18 mm
- Revs 484 mile/ 301 km
- Max Speed 68 mph/ 42 kmh
- Tire Weight 140.5 lbs/ 63.7 kgs
- Approved Rim Width 8.25-9.0 in
- Single Max Load 7390 lbs/ 3352 kgs
- Overall Diameter 0 in/ 0 mm
- Single Inflation Pressure 120 psi/ 827 kpa
- Overall Width 12 in/ 305 mm
- Dual Max Load 6780 lbs/ 3075.4 kgs
- Overall Width Loaded 12 in/ 305 mm
- Dual Inflation Pressure 120 psi/ 827 kpa
